| Wavelength |
190~1100nm |
| Wavelength accuracy |
±2.0nm |
| Wavelength reproducibility |
1nm |
| Monochromator |
Single-beam, C-T type, grating 1200L/mm |
| Photometric accuracy |
±0.5%T |
| Photometric reproducibility |
0.3%T |
| Stray light |
0.1%T (Nal at 220nm, NaNO2 at 340nm) |
| Spectral bandwidth |
2nm (1, 2, 4nm optional) |
| 0%T stability |
0.2%T(30min) |
| 100%T stability |
0.001A/30min (at 500nm, after warming up) |
| Operation mode |
T, A, C, E |
| Photometric range |
-0.3~3A |
| Display |
16X2 LCD |
| Detector |
Silicon Photodiode |
| Light source |
Tungsten halogen lamp, D2 lamp |
| Power Requirement |
220/110V±10%, 50/60Hz |
| Power consumption |
120W |
| Dimensions |
530 × 410 × 210 mm |
| Net weight |
16kg |
